HP DesignJet 510 42-in Printer Demo

Product Specifications & Hardware Details

• Brand: HP
• MPN: CH337A
• Model: DesignJet 510 42-in Printer
• Type: Large-Format Technical Inkjet Plotter
• Standard Functions: 42 in. Large-Format Printing, Single Roll Media Feed, Manual Sheet Feed, Automatic Media Cutter, Hi-Speed USB 2.0 Local Connectivity, IEEE 1284 Parallel Local Connectivity.
• Optional Functions: Wired Network Sharing (Requires upgrading with an HP Jetdirect Internal Print Server card).
• What's Included in the Box: HP DesignJet 510 42-in Printer Engine, Integrated Media Stand and Output Bin, Media Roll Spindle, 4 Starter Ink Cartridges, 4 Separate Printheads, Quick Reference Guide, Setup Poster, Power Cord, and Software Drivers CD.
• Required Items (Sold Separately): Large-format paper rolls or cut sheets up to 42 in. wide, Replacement HP 82 Ink Cartridges (Black, Cyan, Magenta, Yellow), HP 11 Printheads, or a standard USB / Parallel printer data cable.

Technical Specifications

Available Options & Consumables

We stock a full range of official accessories and replacement supplies for the HP DesignJet 510 42-in Printer. You can add these to your order directly from the accessories tab below:

• Memory Upgrades: HP 256 MB Memory Expansion Module (CH654A)
• Network Print Cards: HP Jetdirect 620n Fast Ethernet Internal Print Server (J7934G)
• Ink Tank Supplies: HP 82 Black (69 ml or 28 ml) and Cyan, Magenta, Yellow (69 ml) Ink Cartridges
• Replacement Printheads: HP 11 Black (C4810A), Cyan (C4811A), Magenta (C4812A), and Yellow (C4813A) Printheads

Frequently Asked Questions (FAQ)

• What is the size difference between the CH337A and CH336A models?
  The CH337A version features a larger 42 in. wide media chassis, which allows it to handle full-size engineering sheets (A0 and E-size blueprints). The CH336A version is restricted to smaller 24 in. wide project roles.
• Can this printer handle architectural blueprints and CAD line drawings out of the box?
  Yes. The DesignJet 510 features an embedded hardware HP-GL/2 engine. This ensures precise vector rendering, accurate scaling, and line clarity for complex CAD layout sheets and GIS map prints.
• Does this model feature built-in Wi-Fi wireless networking?
  No. This technical plotting engine relies on built-in physical USB 2.0 or legacy parallel local interfaces. Multi-user network environments require adding a compatible internal HP Jetdirect network card or connecting to a network print server.
