| Printer Type | 8-Color 24-inch Printer |
| Number of Nozzles | Total: 30,720
C, PC, PM, GY: 5,120 nozzles each
BK, MBK, Y, M: 2,560 nozzles each |
| Nozzle Pitch | 1,200 dpi |
| Nozzle Recovery System | Non-firing nozzle detection and compensation |
| Print Resolution (Up to) | Color: 2,400 x 1,200 dpi (Max) |
| OS Compatibility | Windows XP/Server 2003/Server 2008/Vista/7 (32/64 bit), Macintosh OSX 10.3.9-10.6 (32/64 bit) |
| Standard Interfaces | USB 2.0 High-Speed
10/100/1000 Base-T/TX |
| Ink Compatibility | LUCIA EX ink (Pigment-based) |
| Ink Droplet Size | 4 picoliter |
| Ink Capacity | 130ml per color2 |
| Color Set | Cyan, Photo Cyan, Magenta, Photo Magenta, Yellow, Black, Matte Black, Gray |
| Buffer Ram | 384MB |
| Hard Drive | 160GB |
| Media Width | Cut Sheet and Roll: 8-24
Roll: 10-24 |
| Media Thickness | Top Loading Manual Feed: 0.07 - 0.8mm (2.8 - 31.4mil)
Front Loading Manual Feed: 0.5mm - 1.5mm (19.6mil - 59.0mil)
Roll: 0.07 - 0.8mm (2.8 - 31.4mil) |
| Maximum Roll Print Length | 59 Feet (18 meters)3 |
| Maximum Media Roll Diameter | 5.9 (150mm) |
| Borderless Printing Width | 10 (254 mm), B4 (257 mm), A3+ (329 mm), 14 (356 mm), 16 (407 mm), A2 (420 mm), A2+/17 (432 mm), B2 (515 mm), A1 (594 mm), 24 (610 mm) |
| Paper Feed Method | Roll Feed: One Roll, front output
Top Loading Manual Feed: One sheet, front output
Front Loading Manual Feed: One sheet, front output |
| Languages | GARO (Canon Proprietary) |
| Noise Level Approx | Operation: 47 dB (A) or less
Acoustic Power: 6.4 Bels |
| Physical Dimensions | 39 (H) x 46.3 (W) x 34.3 (D) |
| Weight | Approximately 146 lbs with stand |
| Power Source | AC-100-120V (50-60Hz) |
| Power Consumption | Maximum: 100W or less
Standby 7W or less
Power Off: 1W or less (Compliant with Executive Order) |
| Operating Environment | Temperature: 59° -86° F (15° -30° C)
Relative Humidity - 10-80% (No Condensation) |
| User-replaceable items | Print Head (PF-05)
Maintenance Cartridge (MC-16)
Ink Tanks (PFI-105) |
| Software Included | Canon Printer Driver, PosterArtist Lite, Accounting Manager, Print Plug-in for Adobe Photoshop, Print Plug-in for Digital Photo Professional, Print Plug-in for Microsoft Office, Digital Photo Front-Access, Printer Driver Extra Kit (Free Layout, imageRUNNER Linking Function) |
